DOE’s GSL Final Rule Raises Lamp Efficacy Up To 83-195 LPW

On April 12^th, the U.S. Department of Energy (DOE) issued a final rule for General Service Lamp (GSL) standards. The new standards will raise GSL efficacy requirements from the current 45 lpW (aka the backstop), up to 83 – 195 lpW, depending on lamp type and lumen output. The previous 45 lpW backstop was selected to phase out nearly all incandescent and halogen lamps. The new 83 – 195 lpW final rule will likely eliminate every GSL technology except LED, including CFL, OLED, HID, and others.

The new final rule will be enforced starting July 25, 2028. This new final rule follows a significant 2022 expansion in the definition of a GSL. GSLs include A-lamps, directional lamps, specialty lamps, and some LED tube lamps:

“General service lamp means a lamp that has an ANSI base; is able to operate at a voltage of 12 volts or 24 volts, at or between 100 to 130 volts, at or between 220 to 240 volts, or at 277 volts for integrated lamps, or is able to operate at any voltage for non-integrated lamps; has an initial lumen output of greater than or equal to 310 lumens (or 232 lumens for modified spectrum general service incandescent lamps) and less than or equal to 3,300 lumens; is not a light fixture; is not an LED downlight retrofit kit; and is used in general lighting applications. General service lamps do not include:

(1) Appliance lamps;

(2) Black light lamps;

(3) Bug lamps;

(4) Colored lamps;

(5) G shape lamps with a diameter of 5 inches or more as defined in ANSI C79.1-2002;

(6) General service fluorescent lamps;

(7) High intensity discharge lamps;

(8) Infrared lamps;

(9) J, JC, JCD, JCS, JCV, JCX, JD, JS, and JT shape lamps that do not have Edison screw bases;

(10) Lamps that have a wedge base or prefocus base;

(11) Left-hand thread lamps;

(12) Marine lamps;

(13) Marine signal service lamps;

(14) Mine service lamps;

(15) MR shape lamps that have a first number symbol equal to 16 (diameter equal to 2 inches) as defined in ANSI C79.1-2002, operate at 12 volts, and have a lumen output greater than or equal to 800;

(16) Other fluorescent lamps;

(17) Plant light lamps;

(18) R20 short lamps;

(19) Reflector lamps that have a first number symbol less than 16 (diameter less than 2 inches) as defined in ANSI C79.1-2002 and that do not have E26/E24, E26d, E26/50×39, E26/53×39, E29/28, E29/53×39, E39, E39d, EP39, or EX39 bases;

(20) S shape or G shape lamps that have a first number symbol less than or equal to 12.5 (diameter less than or equal to 1.5625 inches) as defined in ANSI C79.1-2002;

(21) Sign service lamps;

(22) Silver bowl lamps;

(23) Showcase lamps;

(24) Specialty MR lamps;

(25) T shape lamps that have a first number symbol less than or equal to 8 (diameter less than or equal to 1 inch) as defined in ANSI C79.1-2002, nominal overall length less than 12 inches, and that are not compact fluorescent lamps;

(26) Traffic signal lamps.”

There are categories of LED lamps that may have trouble meeting the new final rule, including highly decorative lamps, color tuning and color changing lamps, as well as high CRI GSLs. Below are the formula-based efficacy requirements in the final rule. More information is available here.
